Seaking T180 cuts out at full throttle?????

[kfxguy]

the solder joints between your battery wires and esc don't look very good.

I put that esc together for him. what you see is liquid electrical tape over the solder. This is the same exact setup that i had in my rivercat. Is the Lvc programmed off? I WOULD NOT USE the built in bec on 6s. I thought I sent you a external bec with it?


edit. Looks like you have the bec hooked up, did you remove the red wire out of the esc to receiver plug? Looks like its plugged in.....back feeding into the bec is not a good thing.

[revoltrunner]

is the red wire on top of the other one for the bec.

[kfxguy]

is the red wire on top of the other one for the bec.

The smallest wire is for the bec. Next biggest it the cap bank. Then of course the large one is battery.

[T.S.Davis]

Couple observations. Revos are said to deliver more voltage than a standard 6s pack. If the cells are delivering more voltage than the unit is expecting to see maybe that would make it gink out. I don't really know on that.

2000kv is a lot for 6s. High RPM coupled with high.....ish voltage and you might be over 180amps on acceleration and it's cutting you off before bad things happen.

No data. Just food for thought.

[kfxguy]

Couple observations. Revos are said to deliver more voltage than a standard 6s pack. If the cells are delivering more voltage than the unit is expecting to see maybe that would make it gink out. I don't really know on that.

2000kv is a lot for 6s. High RPM coupled with high.....ish voltage and you might be over 180amps on acceleration and it's cutting you off before bad things happen.

No data. Just food for thought.

you have a point about the kv of the motor. My setup was a lower kv motor, I never had an isuue of it cutting out with revos. I even ran the esc on 7s (not this exact one but one just like it) with revos and it lasted a long time till I tried 8s (I know its designed for 6s lol). so I'm thinking the kv could be a little too high or it doesnt like the bec back feeding thats going on OR it messed up something back feeding.

[T.S.Davis]

We've had such good luck with these. I'm reaching probably trying to help. I can't put my finger on what's going on with this one.

[nata2run]

Couple observations. Revos are said to deliver more voltage than a standard 6s pack. If the cells are delivering more voltage than the unit is expecting to see maybe that would make it gink out. I don't really know on that.

2000kv is a lot for 6s. High RPM coupled with high.....ish voltage and you might be over 180amps on acceleration and it's cutting you off before bad things happen.

No data. Just food for thought.

The T180 has a burst of 360A or so. I have personally clocked 385A :-) (Eagle Tree) The ESC's should cope with +-1V easy, as some folks have run this ESC on 7s for a long time. I think the conclusion of this issue should be tested with another ESC of similar kind "seaking/turnigy" (they are cheap these days) It could be anything really? and if OP had it running smooth before and nothing was changed, chances are that something went wrong. They are probably cheap for a reason? A few weeks ago one of mine went for no reason, was doing some testing on the bench. Hooked up the lipo and a small amount of smoke came from one of the resistors near the power leads. There was no reason why this should of happened. Never seen water, never hot, always clean, no problems before, but out of nowhere POOF.

[kfxguy]

We've had such good luck with these. I'm reaching probably trying to help. I can't put my finger on what's going on with this one.

I've had good luck too. Great esc's. Love them. Just wish they would offer a higher voltage one like it and be as robust. I think his problem has something to do with running external bec power into the receiver and also running power into the receiver via the esc's built in bec. That can't be a good thing in my opinion. I was worried that may be a error on my part but I just went back through our emails and saw where I had mentioned not to use the internal bec above 6s and that's why I included an external one and to unplug the red wire on the esc receiver plug.....howver I may have not made that extremely clear. This was sold to him at the time of a death in my family of a close relative (I noticed we had a couple emails back and forth about it) and in my defense I was having a hard time with the sudden loss in my family and I wasn't quite in the right state of mind at that time. So to the op, if it's a problem with the esc, I'll do what I can to get you taken care of. I know he never even mentioned me (and that shows great character on his part!) so whatever we gotta do to get you going. I'll even go as far as buy you another esc and wire it up like that one. Let's see if we can get it lined out first and go from there.

[champion221elite]

I have two of these SK 180 V2 esc's

One has been totally trouble free, and the other gave me fits until I disconnected the internal BEC and run a separate Rx pack.

Both are dedicated 6s setups. On my BJ29, I run a Leopard 3674 motor rated at 1400 kv. On this one, I've never had an issue with heat and run the internal BEC 100% of the time. It's a pretty conservative setup even with an M545 prop.

My other boat is a 29" Sprint Cat running a Leopard 4082 rated at 1600 kv. On this boat, the LVC would cut in at anything over 75% throttle. I had to totally remove the LVC protection and just monitor my packs until I came up with a safe run time. Even still, heat was still an issue for this boat. I disabled the internal BEC and just run an Rx pack. The heat issues are gone now even when turning an X448 prop.

Not saying that's the OP's issue, but 2000 kv on a 6s setup running high voltage packs could be causing the ESC to go into a protection mode and thus killing the throttle until you back off.

[Spartanator]

What radio system are you running?
2000kv on 6s is a bit out of the norm. I have only had issues with my SK180V2s' (V3 is pretty good) when it got wet, the LVC did not work on my Version 2 models though before it got wet... I always time the runs. What is your motor timing? Travis is pretty good at the boat building and setups, he has never ever done me wrong and I have been happy with the RiverCat he built me (Kicking myself for selling it still). Try to get the BEC sorted out first though...

[boatbandit2]

I've had good luck too. Great esc's. Love them. Just wish they would offer a higher voltage one like it and be as robust. I think his problem has something to do with running external bec power into the receiver and also running power into the receiver via the esc's built in bec. That can't be a good thing in my opinion. I was worried that may be a error on my part but I just went back through our emails and saw where I had mentioned not to use the internal bec above 6s and that's why I included an external one and to unplug the red wire on the esc receiver plug.....howver I may have not made that extremely clear. This was sold to him at the time of a death in my family of a close relative (I noticed we had a couple emails back and forth about it) and in my defense I was having a hard time with the sudden loss in my family and I wasn't quite in the right state of mind at that time. So to the op, if it's a problem with the esc, I'll do what I can to get you taken care of. I know he never even mentioned me (and that shows great character on his part!) so whatever we gotta do to get you going. I'll even go as far as buy you another esc and wire it up like that one. Let's see if we can get it lined out first and go from there.

Hey Travis, yes you had a lot on your plate and I appreciate everything you have done, I would never have mentioned you. You build quality parts and boats! The esc was doing before I run the external bec , I run it today with lvc cut off and set to 6s and the red internal bec wire disconnected. It could be just a bad esc.

[boatbandit2]

I was running it on trunigy packs before the revos, my temps are so low i manged to get 119khp, I have a *!***!***!***!**ty video of the boat cut in and out as it was hard to film and control the boat

[boatbandit2]

I have had a T180 in a hobbyking apparition running a 3674 2200kv and trunigy batteries with a x442Rivercat (7).jpgRivercat (8).jpg Here is a clip of it running

[boatbandit2]

Hi i built the boat travis was so kind to build me a esc and send over parts that i couldn't get, he is a top bloke and yes builds super awesome boats. my radio is futaba 3PM-X 3-Channel 2.4GHz Computer Radio

[Peter A]

Ha, was watching the video and recognised the pond at Wattle Downs.
